SAFETY INSTRUCTIONS
This device ͗s electronic chart system (ECS) developed for the navigational aid only and chart itself does not obtain any approvals; has not been certified from the government authorities. If operator needs safe navigation them must use an official chart that has been approved by government agencies also operator is fully responsible for using this device.
Please read through this manual before the first operation. If you have any questions, please contact the customer service or your local dealer or distributor Extensive exposure to heat may result in damage to the chart plotter.
Connection to the power source with revered polarity will damage the chart plotter severely . This damage is not covered by the warranty.
Do not disassemble. The chart plotter contains dangerous high voltage circuits which only experienced technicians must handle
Exposure of the display to UV rays may shorten the life of the liquid crystals used in you plotter. This limitation is due to the current technology of the LCD display. Avoid overheating which may cause loss of contrast and, in extreme case, a darkening of the screen. Problems, which occur from over heating are reversible when temperature decreases.
Screen Cleaning Precautions
Cleaning your chart plotter screen is a very important operation and must be done carefully. The following is the cleaning procedure.
You use a tissue or lens tissue and a cleaning spray containing Isopropanol a normal spray cleaner sold for PC screens. Fold the tissue or lens tissue into a triangular shape, moisten the tip and use the index finger behind a corner to move the tissue across the surface, in overlapping side to side strokes. If the tissue is too wet, a noticeable wet film will be left in its path and you will need to repeat the process. If too dry, the tissue won’t glide easily, and may damage the surface. )
ดาวเทียม SAMYUNG N-800/NF800
GPS LCD COLOR PLOTTER
1. Introduction
General Information
The chart plotter is a precision-crafted GPS chart Plotter with high-performance receiver for the Global Positioning System
Constellation of satellites, providing precise location data with a host of navigation features. Some functions require optional units and sensors installed on your boat.
The chart plotter can be connected to external devices with NMEA01863 interface and display information.
Following are the examples.
- NAVTEX
- AIS receiver
- DSC VHF radio
- Transducer & sensors
- Autopilot
Specification
NF800
GENERAL |
|
Category |
Detail |
Size |
227mm(H)x257mm(W)x119mm(D) |
Display |
8 inch, 640 x 480 pixel |
Supply Voltage |
11 ̴ 35V DC Approx 40W |
Supply Curent |
13.8 V 1.0A – LCD minimum brightness. 1.5A - LCD minimum brightness |
Temperature |
Antenna : -30 ̊C ̴ +85 ̊C, Main unit : -15 ̊C ̴ +55 ̊C |
ALARMS |
|
User set: Arrival radius, loss od DGPS fix, anchor, dangerous AIS vessels |
|
GPS NAVIGATION |
|
Chart card |
NAVIONICS SD Card |
User card |
SD Card |
Waypoints |
Up to 1,000 |
Routes |
20 routes (1 routes – 20 points) |
Tracks |
2000 tracks |
Chart datums |
216 Chart datums, One user- defined map shift. |
Chart scale |
0.2 to 500nm for chart (chart dependent) down to 0.005 nm in plotter mode. |
COMMUNICATIONS |
|
NMEA |
NMEA 0183-Port1 port: 4800, 9600, 38400 |
NMEA 0183 Input |
DBK, DBS, DBT, DPT, GGA, GLL ,GNS, GGA,GSV, HDG, HDT MDA, MTA, MTW,MWD, MWV, RMC, RPM, VHW,VTG, VWT, ZDA |
NMEA 0183 output |
APA, APB, BWR, GGA, GLL, GSA, GAV, RMB, RMC, VTG XTE, DBT, DPT, VHW, MTW, ZDA, PLT |
Fish finder |
|
Depth |
0 m ̴ 600m |
Output of transducer |
Power : Maximum 600 W RMS |
|
2 type frequency (50 kHz, 200 kHz) |
Temperature |
range : 0 ̊ ̴ 37.7 ̊C (32 ̊ F ̴ 99.9 ̊ F) |
Speed (Paddle wheel) |
1 ̴ 96.6 kph, ( 57.5 mph, 50 kn ). |
Packing List
Item List |
Model |
|
|
NF800 |
N800 |
Display |
NF800-E |
N800-E |
Bracket |
ACC-PLOT-064 |
|
Display Cover |
NF800-CC |
|
Power Cable |
SCN-3M-D3 |
|
Bracket mounting screw |
NF800-BP |
|
Protection Cover |
ACC-CABA-064 |
|
User manual |
NF800-BE |
|
GPS Antenna |
SAN-60-10m |
|
Quick User Guide (Eng) |
NF800-BE |
|
B45 Transducer |
B45 |
X |
Optional Accessories
Item List |
Part number |
list |
|
|
GPS Antenna + BNC Plug |
GPS Antenna + |
SAN-60-20m |
GPS Antenna support |
GPS Antenna support |
|
GPS Antenna cable (20m) |
GPS Antenna stand support |
57745 |
GPS Antenna stand support |
Remote |
REM-350-E |
Optional item |
B45 transducer |
B45 |
Optional item |
SPARE FUSE |
12V/7A, 24V/3A |
3A: 2EA, 7A: 2EA |
|
